RT-6116

The RT-6116 radiates in its new design – featuring an ultra-slim and sleek look that exhibits elegance. It is uncompromising to the space requirements and provides better cable management and easy maintenance. The RT-6116 is taking POS terminal design into the next level, setting your brand image apart from the others.

Slim & Stylish Look

With sleek contours, ultra-slim body, and linear rear cover surface, the RT-6116 features a 15.6" PCAP touch screen, and full suite of ports that are hidden in the clean rear cover. No screws can be found on its surface maintaining a neat and sleek look.

Clean Cable Management

Advanced cable management design delivers a truly clutter-free station. The standard base can house the optional Powered USB or USB extension module, while the optional base integrates a UPS backup (RB-5000) for the event of a power failure.

Save Your Time and Money

The terminal can be shipped with customer line display or 9.7” / 10” 2nd customer facing LCD display attached and folded, saving deployment time as well as shipping costs.

Fanless Technology

The patented fan-less technology allows the terminal to run quietly in all kinds of harsh conditions and – at the same time - provides a long service life.

Faster Installation and Serviceability

Rear cover can be removed easily and without tools, thus allowing faster installation and serviceability.

RT-6016 Specification (Tablet Only)

  • Processor: Intel Whiskey Lake Core i5-8365UE;
                      Intel Whiskey Lake Core i7-8665UE
  • OS Support: Windows 10 IoT 64 bits
  • System Memory: DDR4 SO-DIMM slot x 2, max. 32GB
  • Storage Device: SATA x 2
  • RAID Function: Yes, SATA SSD default x 2
  • Intel vPro Support: Yes, with Core i5 & i7
  • TPM Support: Yes, TPM 2.0
  • Power Supply: 12V/60W
                            12/150W with optional PoweredUSB module

Display & Touch

  • LCD: 15.6" TFT LCD
  • Resolution: 1920 x 1080
  • Touch: True-flat PCAP touch with multi-touch support (IP65 on front panel)

I/O Expansion

  • Serial Port: 3, DB9 x 1 + RJ50 x 2, 5V/12V support on all COM ports
  • Parallel Port: N/A
  • Standard USB Port: 5, USB 3.0 x 2 + USB 2.0 x 3
  • PoweredUSB Port: Optional Powered USB module with 24V + 12V (USB 2.0 x 1 will no longer be available with the Powered USB module)
  • OTG USB: N/A
  • LAN Port: 10/100/1000 Mb x 1
  • Display Port: VGA via proprietary connector (12V support for Posiflex monitors) x 1+ mini DP x 1
  • CR Port: 1, control 2 CR via optional Y-cable, supporting 24V cash drawer
  • PS/2 Port: N/A
  • UPS Port: N/A
  • Audio: Internal 2W speaker x 1
  • Expansion Slot: M.2 slot x 1

Physical Dimension (Tablet Only)

  • Dimension (W x D x H in mm): 402 x 207 x 297
  • Weight (N. W. in g): 5

Environmental

  • Operation Condition: 0°C - 40°C, 20%RH - 90%RH
  • Storage Condition: -20°C - 70°C, 10%RH - 90%RH

Built-in Options

  • WiFi: M.2 WiFi/BT module
  • Camera: 1MP wide angle camera
  • MSR: N/A
  • AG Glass: Cannot co-exist with built-in camera

Attachment Options

  • POS Monitor: Non-touch TFT LCD: 9.7"/10.1"/15";
                           PCAP touch TFT LCD: 9.7"/10.1"
  • Line Display: 2 x 20 rear-mount VFD customer line display
  • External UPS Pack For RT Series: UPS battery module (12V/2300mAh)
  • Attachment: MSR; iButton; 2D Scanner; RFID; Fingerprint Sensor
