Sleek Design, Proven Quality

More than just visual appeal, the fanless architecture allows the terminal to run in harsh or high-traffic environments and under near-silent operation.

Versatility For Every Demand

It can be customized for each specific usability requirements – in a kiosk, on a pole with mounting and hardware options.

Applications

Retail
- Self-service i.e. Price Checker
- Interactive Kiosk
- Advertising
Food Service
- Self-ordering kiosk
- Kitchen Display System (KDS)
- Advertising
Healthcare
- Self-service i.e. Price
- CheckerInteractive Kiosk
- Point-of-Information

HC-1621P Specification (Tablet Only)

Processor:
Intel Kaby Lake Core i3-7101TE, up to 3.40 GHz, 3M Cache;
Intel Kaby Lake Core i5-7500T, up to 3.30 GHz, 6M Cache;
Intel Kaby Lake Celeron G3930TE, up to 2.70 GHz, 2M Cache
OS Support: Windows 10 IoT 64 bit
System Memory: DDR4 SO-DIMM x 2, max. 32GB in 2 slots
Storage Device: SATA connectorx 1 + M.2 connector [support AHCI] x 2
RAID Function: N/A
Intel vPro Support: N/A
TPM Support: Yes
Power Supply: 12V/84W

Display & Touch

LCD: 21.5" TFT LCD
Resolution: 1920 x 1080
Touch: True-flat PC. P touch with multi-touch support (IP65 on front panel)

I/O Expansion

Serial Port: 4, DB9 x 4, 5V/12V support on all COM ports
Standard USB Port: 7, USB 3.0 x 4 + USB 2.0 x 3
OTG USB Port: N/A
LAN Port: 10/100/1000 Mb x 2
Display Port: VGA x 1 + HDMI x 1, 12V support on VGA port for Posiflex monitors
CR Port: N/A
Audio: Internal 3W speaker x 2 + Mic-in/Line-out
Expansion Slot: M.2 slot x 1
Buttons: Volume up, volume down, brightness up, brightness down, power (hotkeys lockable)
